New KESS3 Upgrade-Pack: maximize your work on the latest supported work vehicles.

  • KESS3
  • [post-views]

Efficiency and Safety with KESS3

Work via OBD on Delphi DCM2.7AP ECUs installed on JCB machines powered by the 4.4-liter Diesel-Max engine, ensuring fast and secure access to vehicle data directly through the diagnostic port, without the need to remove the ECU, drastically reducing machine downtime.

Do you need deep-level recalibration? Operate in BOOT mode on Caterpillar and Perkins engines with Caterpillar A6E2, Caterpillar A6M12, Denso A6E10, and A6E11 ECUs, offering in-depth and effective recalibration that reveals all the details of the engine control electronics.

With KESS3 and this new protocol release, you can also tackle the most complex configurations affecting operational efficiency: solve issues related to the functioning of specific combustion treatment and post-treatment systems with a service that strengthens customer loyalty.

Focus on Repair

This new update also includes the ability to clone two new ECUs: Denso 276022-0030 and Denso 112500-1022, equipped on compact loaders from Kubota, John Deere, and Caterpillar. Thanks to this feature, you can intervene comprehensively, not only for tuning and optimization of small Kubota and Yanmar engines but also for repair, including full system restoration, ensuring a complete and highly professional service.

ECU – BENCH/BOOT

  • Denso 276022-0030
  • Denso 112500-1022
  • Caterpillar A6E2
  • Caterpillar A6M12
  • Denso A6E10
  • Denso A6E11

ECU – OBD

  • Delphi DCM2.7AP

Denso 276022-0030

CATERPILLAR

RD, WR and Clone in Boot Mode

Skid Steer Loader299D2 3.8LDiesel69kW

KUBOTA

RD, WR and Clone in Boot Mode

Skid Steer LoaderSLV95-2 – 3.8LDiesel72kW
M SeriesM135GX-II 6.1LDiesel99kW

Denso 112500-1022

JOHN DEERE CONTRUCTION

RD, WR and Clone in Bench Mode

Skid Steer Loader332E 3.1L I4Diesel75kW
Skid Steer Loader328E 3.1L I4Diesel64kW

Caterpillar A6E2

CATERPILLAR

RD, WR in Boot Mode

Excavators336E 9.3LDiesel236kW
Excavators330 7.1LDiesel204kW
Wheel Loader950 7.1LDiesel186kW
Wheel Loader926M 7.1LDiesel125kW
Excavators320FL 4.4LDiesel121kW
Excavators336F 9.3LDiesel234kW
BulldozersD6 9.3L l6Diesel161kW
Material HandlerMH3050Diesel258kW
Wheel Loader972XEDiesel253kW
Material HandlerMH3250Diesel232kW
Wheel Loader966XEDiesel222kW
Excavators349 GCDiesel261kW
Excavators350 MHPUDiesel251kW
Excavators350Diesel251kW
Excavators340Diesel231kW
Excavators345 GCDiesel209kW
Excavators333Diesel222kW
Earthmoving Compactor816Diesel174kW
Excavators336 MHPUDiesel168kW
Excavators336 GCDiesel168kW
Excavators336Diesel168kW
Excavators335Diesel169kW
Medium DozerD7Diesel197kW
Motorgrader140 GC AWDDiesel172kW
Motorgrader140 GCDiesel172kW
Motorgrader140 AWDDiesel172kW
Motorgrader140Diesel172kW
Medium DozerD6XEDiesel161kW
Medium DozerD6Diesel161kW
Earthmoving Compactor816Diesel153kW
Excavators330 GCDiesel166kW
Excavators330Diesel166kW
Wheel Loader950GCDiesel168kW
Earthmoving Compactor815Diesel136kW
Excavators325Diesel140kW
Excavators326 GCDiesel142kW
Excavators326Diesel142kW
Earthmoving Compactor815Diesel129kW
Material HandlerMH3024Diesel128kW
Excavators323 GXDiesel119kW
Excavators323 GCDiesel119kW
Excavators323Diesel119kW
Material HandlerMH3022Diesel108kW
Motorgrader120 GC AWDDiesel104kW
Motorgrader120 AWDDiesel104kW
Paving CompactorCS78BDiesel127kW
Medium DozerD5Diesel127kW
Medium DozerD4Diesel97kW
Motorgrader120 GCDiesel104kW
Motorgrader120Diesel104kW
Wheel Loader926MDiesel125kW
Wheel Loader962MDiesel202kW
Power GeneratorXQP115Diesel106kW
Excavators320 GXDiesel107kW
Excavators320 GCDiesel107kW
Excavators320Diesel107kW
Excavators317Diesel94kW
Power GeneratorDE400SGCDiesel400kW
Power GeneratorDE400GCDiesel400kW
Power GeneratorDE400SGCDiesel350kW
Power GeneratorDE400GCDiesel350kW
Wheel Loader972Diesel298kW
Wheel Loader966Diesel298kW
Wheel Loader966Diesel261kW
Relaimer MixerRM400Diesel310kW
Power GeneratorXQP310Diesel350kW
Power GeneratorDE350SGCDiesel300kW
Power GeneratorXQP310Diesel280kW
Power GeneratorDE350SGCDiesel230kW
Wheeled ExcavatorMH3040Diesel208kW
Wheeled ExcavatorMH3040Diesel185kW
Wheeled ExcavatorM319Diesel145kW
Wheeled ExcavatorM319Diesel129kW
Wheeled ExcavatorM318Diesel145kW
Wheeled ExcavatorM318Diesel129kW
Wheeled ExcavatorM320Diesel145kW
Wheeled ExcavatorM320Diesel129kW
Wheeled ExcavatorM322Diesel145kW
Wheeled ExcavatorM322Diesel129kW
Wheeled ExcavatorMH3026Diesel145kW
Wheeled ExcavatorMH3026Diesel129kW
Wheel Loader938MDiesel140kW
Wheel Loader938MDiesel128kW
Wheel Loader950GCDiesel180kW
Wheel Loader950GCDiesel160kW
Wheel Loader966GCDiesel218kW
Wheel Loader966GCDiesel194kW
Wheel Loader950ZDiesel180kW
Wheel Loader950ZDiesel160kW
Wheel Loader950MDiesel180kW
Wheel Loader950MDiesel160kW
Wheel Loader962ZDiesel230kW
Wheel Loader962ZDiesel180kW
Wheel Loader962MDiesel230kW
Wheel Loader962MDiesel180kW
Cold PlanerPM310Diesel264kW
Cold PlanerPM310Diesel236kW
Cold PlanerPM313Diesel281kW
Cold PlanerPM313Diesel261kW
Cold PlanerPM312Diesel264kW
Cold PlanerPM312Diesel236kW
Wheel Dozer814Diesel174kW
Wheel Dozer814Diesel153kW
Soil CompactorCP74BDiesel153kW
Soil CompactorCS74BDiesel153kW
Soil CompactorCS19Diesel164kW
Soil CompactorCS17Diesel153kW
Soil CompactorCS16Diesel142kW
Soil CompactorCS13Diesel142kW
Soil CompactorCS76BDiesel142kW
Soil CompactorCS66BDiesel129kW
Track Loader953Diesel118kW
Track Loader963Diesel205kW
Track Loader963Diesel193kW
Power GeneratorXQP200Diesel210kW
Power GeneratorXQP200Diesel136kW
Wheeled ExcavatorM317Diesel105kW
Wheeled ExcavatorM317Diesel95kW
Wheeled ExcavatorM316Diesel105kW
Wheeled ExcavatorM316Diesel95kW
Wheeled ExcavatorM315GCDiesel123kW
Wheeled ExcavatorM315GCDiesel107kW
Wheeled ExcavatorM315Diesel123kW
Wheeled ExcavatorM315Diesel107kW
Wheeled ExcavatorM314Diesel105kW
Wheeled ExcavatorM314Diesel95kW
Soil CompactorCP16Diesel97kW
Soil CompactorCP56BDiesel97kW
Soil CompactorCP68BDiesel108kW
Soil CompactorCS68BDiesel108kW
Soil CompactorCS56BDiesel97kW

EAGLE CRUSHER

RD, WR in Boot Mode

Ultramax1200-CC Crushing PlantDiesel340kW

EDGE INNOVATE

RD, WR in Boot Mode

Roll SizerRS1500 9.3LDiesel260kW

EPIROC

RD, WR in Boot Mode

SmartROCT40 7.1LDiesel168kW

POWERSCREEN

RD, WR in Boot Mode

Metrotrak4.4LDiesel129kW

TESAB

RD, WR in Boot Mode

Impact Crushers1012S 9.3LDiesel205kW

VERMEER

RD, WR in Boot Mode

Horizontal GrindersHG4000 12.5LDiesel400kW

WEILER

RD, WR in Boot Mode

Feller BunchersB670A 7.1LDiesel180kW
Feller BunchersB458 9.3LDiesel222kW
Feller BunchersB457 9.3LDiesel222kW
Knuckleboom LoadersK860 7.1LDiesel151kW
Knuckleboom LoadersK770 4.4LDiesel137kW
Knuckleboom LoadersK660 7.1LDiesel151kW
Knuckleboom LoadersK562 4.4LDiesel137kW
Knuckleboom LoadersK560 4.4LDiesel137kW

Caterpillar A6M12

CATERPILLAR

RD, WR in Boot Mode

Excavators301.5 CR 1.1LDiesel16kW
Excavators301.7 CR 1.1LDiesel16kW
Excavators301.6 1.1LDiesel16kW
Excavators301.8 1.1LDiesel16kW
Excavators307.5 2.43LDiesel42kW
Excavators310 3.33LDiesel52kW
Excavators306 CR 2.43LDiesel42kW
Excavators309 CR VAB 3.33LDiesel52kW
Excavators309 CR 3.33LDiesel52kW
Excavators308 CR VAB 3.33LDiesel52kW
Excavators308 CR 3.33LDiesel52kW
Excavators302 CR 1.1LDiesel16kW
Backhoe Loader450 4.4LDiesel98kW
Backhoe Loader440 4.4LDiesel78kW

Denso A6E10

CATERPILLAR

RD, WR in Boot Mode

C2.22.2L l4Diesel49kW
Excavators305 CR 1.7LDiesel34kW

REFORM

RD, WR in Boot Mode

MetracH75 Pro 2.8L l4Diesel55kW
MetracH75 2.8L l4Diesel55kW

SAME TRACTORS

RD, WR in Boot Mode

Delfino60 2.2L l4Diesel44kW
Delfino50 2.2L l4Diesel38kW
Delfino50 Basso 2.2L l4Diesel38kW

Denso A6E11

CATERPILLAR

RD, WR in Boot Mode

BulldozersD3 3.6L l4Diesel78kW
Skid Steer Loader246D 3.3L l4Diesel54kW
Excavators315 GC 3.6L l4Diesel74kW
Backhoe Loader434 3.6L l4Diesel74kW
Wheel Loader914 3.6L l4Diesel74kW

FRASTE

RD, WR in Boot Mode

MultidrillML 3.6L l4Diesel90kW

HIDROMEK

RD, WR in Boot Mode

Backhoe LoaderHMK 102B 3.6L l4Diesel74kW

LINDNER

RD, WR in Boot Mode

Lintrac100 3.6L l4Diesel86kW
Lintrac80 3.6L l4Diesel74kW
Lintrac95 LS 3.6L l4Diesel75kW
Lintrac130 3.6L l4Diesel100kW
Lintrac75 LS 3.6L l4Diesel55kW
Lintrac115 LS 3.6L l4Diesel82kW
Unitrac92 P5 3.6L l4Diesel74kW
Unitrac72 P5 3.6L l4Diesel55kW

MECALAC

RD, WR in Boot Mode

DumperTA9S 3.6L l4Diesel55kW
DumperTA9 3.6L l4Diesel55kW
DumperTA6S 3.6L l4Diesel55kW
DumperTA6 3.6L l4Diesel55kW

MERLO

RD, WR in Boot Mode

TurbofarmerTF 42.7CS-136 3.6L l4Diesel100kW
TurbofarmerTF 42.7-136 3.6L l4Diesel100kW
TurbofarmerTF 42.7CS-116 3.6L l4Diesel86kW
TurbofarmerTF 42.7-116 3.6L l4Diesel86kW

REFORM

RD, WR in Boot Mode

MetracH95 Pro 3.6L l4Diesel70kW
MetracH95 3.6L l4Diesel70kW

WEIDEMANN

RD, WR in Boot Mode

Wheel Loader5080T 3.6L l4Diesel100kW

Delphi DCM2.7AP

JCB

RD, WR in OBD

Telehandler536-95 Agri 4.4L I4Diesel81kW
Telehandler560-80 Agri 4.4L I4Diesel93kW
Telehandler532-60 Agri 4.4L I4Diesel93kW
Telehandler510-55TC 4.4L I4Diesel81kW
Telehandler512-26TC 4.4L I4Diesel93kW
Telehandler514-56 4.4L I4Diesel81kW
Telehandler509-45TC 4.4L I4Diesel81kW
Telehandler536-95 4.4L I4Diesel93kW
Telehandler512-56 4.4L I4Diesel81kW
Telehandler542-70 Agri 4.4L I4Diesel93kW
Telehandler510-42 4.4L I4Diesel81kW
Telehandler509-42 4.4L I4Diesel81kW
Telehandler510-56 4.4L I4Diesel81kW
Telehandler514-56 Agri 4.4L I4Diesel81kW
Telehandler538-60 Agri 4.4L I4Diesel93kW
Telehandler538-60 Agri 4.4L I4Diesel81kW
Telehandler509-23TC 4.4L I4Diesel81kW
Telehandler531-70 Agri 4.4L I4Diesel93kW
Telehandler531-70 Agri 4.4L I4Diesel81kW
